2.4 Is b in the Span?

The previous section closed with a promise: everything a matrix produces is automatically a subspace, since it is assembled by adding and scaling and the subspace test asks for nothing else. Cashing the promise takes one piece of notation. Let $A$ be the $3 times 2$ matrix whose columns are $𝐯 sub 1 equals open parenthesis 1, 0, 0.5 close parenthesis$ and $𝐯 sub 2 equals open parenthesis 0, 1, 0.5 close parenthesis$ , and let $𝐱 equals open parenthesis x sub 1, x sub 2 close parenthesis$ . The matrix–vector product $A 𝐱$ is defined to be the combination of the columns weighted by the entries of $𝐱$ :

$A 𝐱 = x_{1} 𝐯_{1} + x_{2} 𝐯_{2} = (x_{1}, x_{2}, 0.5 x_{1} + 0.5 x_{2})$

That is the whole definition, and it is the operation you have run since this chapter's first section. Letting $𝐱$ range over $ℝ^{2}$ produces every scaled sum of $𝐯 sub 1$ and $𝐯 sub 2$ — their span, nothing more. Writing $x equals x sub 1$ and $y equals x sub 2$ , the third coordinate is always $0.5 x plus 0.5 y$ , so what $A$ can produce is the plane $z = 0.5 x + 0.5 y$ through the origin. Section 2.8 will call it the column space of $A$ ; for now, call it what $A$ can reach.

Now run the question backwards. Given a target $𝐛$ in $ℝ^{3}$ , is there an $𝐱$ with $A 𝐱 = 𝐛$ ? The definition answers geometrically before any arithmetic starts: $A 𝐱 = 𝐛$ has a solution exactly when $𝐛$ lies in the span of the columns of $A$ . Consistency is not an accident discovered at the bottom of an elimination; it is the question of whether one point sits on one plane. The figure below puts a target on a vertical track through that plane so you can watch consistency come and go.

A semi-transparent tilted plane through a marked origin: the set of all vectors A times x, spanned by a short red arrow to (1, 0, 0.5) and a short blue arrow to (0, 1, 0.5) that both lie flat in it. A third, amber arrow runs from the origin to the target b = (1, 1, c), whose height is set by a slider c. A thin dashed red segment rises vertically from the point (1, 1, 1) on the plane to the amber arrow's tip, measuring how far b misses the plane. Dragging c to 1 shrinks the dashed segment to nothing and lays the amber arrow flat in the plane, exactly on the diagonal between the red and blue arrows; at every other c the amber tip floats off the plane and the dashed miss reappears. — The plane $z = 0.5 x + 0.5 y$ — everything $A$ can reach — with the red column $𝐯 sub 1 equals open parenthesis 1, 0, 0.5 close parenthesis$ and the blue column $𝐯 sub 2 equals open parenthesis 0, 1, 0.5 close parenthesis$ lying flat inside it. The amber arrow is the target $𝐛 equals open parenthesis 1, 1, c close parenthesis$ , and the dashed red segment runs from the plane's point $open parenthesis 1, 1, 1 close parenthesis$ to the amber tip: it is the miss, and its length is $vertical bar c minus 1 vertical bar$ .

Explore the figure

At the default $c equals 1$ the dashed segment has vanished and the amber arrow lies flat in the plane. Orbit until you see its tip close the parallelogram built on the red and blue arrows: $𝐛 = 𝐯_{1} + 𝐯_{2}$ , so $𝐱 equals open parenthesis 1, 1 close parenthesis$ .
Drag $c$ up to $2$ . The tip lifts to $open parenthesis 1, 1, 2 close parenthesis$ while the plane above $open parenthesis 1, 1 close parenthesis$ stays at height $0.5 (1) + 0.5 (1) = 1$ , and a dashed segment one unit long opens up. No combination of the red and blue arrows can climb it — both are stuck in the sheet.
Drag $c$ down to $minus 2$ . The miss is three units and hangs below the plane, but nothing has changed in kind: unreachable is unreachable, above or below.
Sweep $c$ and count the values that make the system solvable. This plane is a graph $z = 0.5 x + 0.5 y$ , so it has exactly one height above $open parenthesis 1, 1 close parenthesis$ and the vertical line meets it exactly once: the answer is one value, not an interval. Where would the crossing sit if the second column were $open parenthesis 0, 1, 1.5 close parenthesis$ ?

Where the miss becomes a number

Elimination says the same thing arithmetically. The augmented matrix for $𝐛 equals open parenthesis 1, 1, c close parenthesis$ has rows $open parenthesis 1, 0 ∣ 1 close parenthesis$ , $open parenthesis 0, 1 ∣ 1 close parenthesis$ and $open parenthesis 0.5, 0.5 ∣ c close parenthesis$ . The first two are already pivots, so clear the third with them: subtract $0.5$ times row one and $0.5$ times row two from row three. Its coefficients die, its augmented entry becomes $c - 0.5 (1) - 0.5 (1)$ , and the last row is left reading

$0 = c - 1$

which is the dashed segment written as an equation — its length was $vertical bar c minus 1 vertical bar$ all along. At $c equals 1$ that row is $0 equals 0$ , a true statement constraining nothing, and the two pivot rows hand over the unique solution $𝐱 equals open parenthesis 1, 1 close parenthesis$ .

open bracket 1, 0, 1; 0, 1, 1; 0, 0, 0 close bracket

The consistent case, c = 1 ✓ Computed · mojocas 0.1.0 ✓ Agrees with the text

The augmented matrix for $𝐛 equals open parenthesis 1, 1, 1 close parenthesis$ , reduced by a computer algebra system. The bottom row is all zeros: the third equation followed from the first two, no pivot lands in the augmented column, and the coefficient pivots read off $x_{1} = x_{2} = 1$ .

At any other $c$ the last row reads $0 equals$ a nonzero number, and no choice of $x sub 1, x sub 2$ repairs it; reduced form scales that bad row to $0 equals 1$ , a pivot in the augmented column. That is the general test: a system is inconsistent exactly when its reduced augmented matrix has a pivot in the last column, because such a pivot is a row asserting $0 equals 1$ .

open bracket 1, 0, 0; 0, 1, 0; 0, 0, 1 close bracket

The inconsistent case, c = 2 ✓ Computed · mojocas 0.1.0 ✓ Agrees with the text

The same computation for $𝐛 equals open parenthesis 1, 1, 2 close parenthesis$ . The identity matrix is bad news here, not good: the pivot in the third column is the row $0 equals 1$ — elimination finding, from the numbers alone, the vertical miss of one unit visible in the figure.

Two consequences. $A$ has only two columns, so its reach is at most a plane and most vectors of $ℝ^{3}$ are unreachable. And a reachable target is reachable in exactly one way, since both coefficient columns hold pivots and no free variable is left to vary.
